A type B backing track is anchored with number ten sheet metal screws spaced at twelve inches on center maximum. Gypsum wallboard panels abut at the partition joint with a revealed gap. Framing members and fasteners provide alignment and support for the wallboard finish.
DETAIL A #10 SMS, 12" O.C. MAX BACKING TRACK TYPE B,
