A non-rated wall framing assembly intersects a fire-rated wall assembly as scheduled. Continuous gypsum board facing is installed behind the intersecting wall framing to maintain the rated partition integrity. Both wall assemblies feature stud framing with batt insulation and multiple layers of gypsum board facing on each side.
CONTINUOUS GYP. BD. FACING BEHIND INTERSECTING WALL FRAMING FIRE RATED WALL ASSEMBLY AS SCHED. NON-RATED WALL ASSEMBLY AS SCHED. INTERSECTING WALL FRAMING
