An elevator door frame is installed at the head of a six-inch metal stud wall framed with cold-formed steel studs and faced with Type X gypsum board on both sides. A continuous joint sealant is applied around both sides of the door frame head junction.
TYPE 'X' GYPSUM BOARD 6" METAL STUD WALL SEAL AROUND BOTH SIDES (TYP) ELEVATOR DOOR FRAME
