A-YGYG7 — Base Detail

Architectural · A-YGYG7

Base Detail

Scale: SCALE: 6" = 1'-0"
Units: imperial
Sheet: A-554
Discipline: Architectural

Materials

Elements

Anchors / Embeds Columns Connections / Plates Railings / Guards

Connections

Base Plate / Anchorage Embed Plate

Text on the drawing

2" X 2" X 3/8" STEEL POST CONNECTED TO EMBED PLATE ESCUTCHEON PLATE SECTION SET SCREW - CONCEALED BY PLUG
