A-Y9KRT — Bollard Pb

Architectural · A-Y9KRT

Bollard Pb

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A504
Discipline: Architectural

Materials

Elements

Foundations / Footings Site / Paving Vaults / Domes

Text on the drawing

CONCRETE FILLED 6" DIA SCH. 40 GALV. PIPE GRADE OR PAVEMENT 3000 PSI CONC. DOME CONCRETE FILL 4‘-0" 4‘-6" 1' - 0" 6" NOTE: PAINT INTERIOR BOLLARDS SAFETY YELLOW PAINT EXTERIOR BOLLARDS COLOR TBD

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
