Double cold-formed metal studs frame the rough opening with sizing per partition types. The bottom track has cut flanges with the stud turned up. Three number ten flat-head sheet metal screws secure each side of the track. Powder-actuated fasteners with a 0.145-inch diameter and 1-1/2-inch embedment anchor the track at 16 inches on center.
6" 3" DOUBLE METAL STUDS AT OPENING. REFER TO PARTITION TYPES. (3) #10 F.H. S.M.S. EACH SIDE BOTTOM TRACK. CUT FLANGES AND TURN UP STUD 0.145" DIA. HILTI X-DNI POWDER ACTUATED FASTNERS W/ 1-1/2" EMBEDMENT @ 16" 0.C. - ICBO #2388
