A structural steel angle jamb configured per the manufacturer's requirements mounts directly against a cast-in-place concrete wall. Metal panels with a finish color matching adjacent vertical fins align near a precast concrete panel located below. Dashed lines indicate the alignment of a precast panel positioned above.
2 CAST IN PLACE CONCRETE WALL STEEL ANGLE JAMB PER MFR METAL PANEL, FINISH COLOR TO MATCH VERTICAL FINS LINE OF PRECAST PANEL, ABOVE PRECAST PANEL
