An acoustic ceiling panel designated ACP meets a gypsum wallboard partition above a scheduled door frame. The wall assembly incorporates gypsum wallboard and wood wall paneling designated WD-1 per schedule. An acoustic ceiling panel designated ACP-3 interfaces with the wall near the door header with alignment verified per the reflected ceiling plan. Six-inch vertical dimensions establish the spacing of the ceiling and wall transitions.
