A diagonal brace extends upward from a non-bearing stud wall top track at approximately a forty-five degree angle. The bottom of the brace features a clipped flange forming a shoe secured with three screws on each flange to the top track. The upper end of the brace connects to a deep leg track anchored to the overhead structure using four powder-actuated fasteners.
45°± SCREW ATTACHMENT (3) EACH FLANGE CLIP FLANGE TO FORM SHOE A TOP TRACK CEILING LINE A SIDE VIEW NON-BEARING STUD WALL ANCHORAGE (4) POWDER ACTUATED FASTENERS DEEP LEG TRACK
