This upper cabinet assembly features a three-quarter-inch plywood hinged door covered with a plastic laminate finish on all exposed surfaces and equipped with two self-closing concealed satin stainless steel hinges per door. The interior features a black or white melamine finish matching the exterior, paired with three-quarter-inch adjustable plywood shelves supported by four stainless steel shelf pins per shelf. An integral door pull is integrated into the design, and a one-inch header sits flush with the cabinet where applicable. The general contractor provides clearance as required by code.
INTEGRAL DOOR PULL. GC TO PROVIDE CLEARANCE AS REQUIRED BY CODE 3/4" PLYWOOD HINGED DOOR COMPLETE WITH P-LAM (PL-1) ON ALL EXPOSED SURFACES. REFER TO FINISH PLAN FOR SPECIFICATIONS. PROVIDE SELF-CLOSING CONCEALED HINGES (2 PER DOOR) IN SATIN STAINLESS STEEL FINISH. REFER TO RCP FOR CEILING HEIGHT MIN. 0' - 1" VARIES SEE ELEVATION (1) 3/4" ADJUSTABLE PLYWOOD SHELF - P-LAM (PL-1) ON ALL EXPOSED SURFACES. PROVIDE STAINLESS STEEL SHELF PINS (4 PER SHELF). BLACK OR WHITE MELAMINE INTERIOR. TO MATCH COLOR OF EXTERIOR FINISH. REFER TO ELEVATION FOR FINISH 1" HEADER FLUSH WITH CABINET IF APPLICABLE. REFER TO ELEVATION FOR MORE INFORMATION. TYP 0' - 3" TYP 0' - 3" REFER TO ENLARGED RCP
