An anodized black aluminum mullion measuring four inches by two inches or two inches by two inches connects to a concrete panel leg sized per structural drawings with a four-inch dimension. Glazing extends into the framing per elevations and typical specifications. A ventilation hole is provided behind spandrel glazing with sac and patching around the hole. Frame lap over glass edge, minimum glass clearance, and required glass supports comply with section 5404 of the Uniform Building Code.
