A pipe penetrates through a metal fabric system centered within a three-foot framed opening. Two U-shaped flat bar frame halves clamp the metal fabric around the perimeter at the front elevation. Clamping flat bars secure the perimeter at the back elevation with mechanical fasteners.
METAL FABRIC SYSTEM PIPE PENETRATION THROUGH METAL FABRIC TYP 1" (2) "U" FLAT BAR FRAME HALVES AT FRONT ELEVATION CLAMPING FLAT BARS AROUND PERIMETER AT BACK ELEVATION 3' - 0" EQ EQ SCALE: 5 METAL FABRIC AT INTERMEDIATE LINK
