A scribed filler panel is cut to fit against the side wall, featuring a plastic laminate finish matching the casework face. Wood blocking is installed behind the filler panel to secure it to the wall. The filler dimension ranges from a minimum of 1 inch to a maximum of 3 inches.
SCRIBED FILLER PANEL CUT TO FIT, WITH PLASTIC LAMINATE FINISH TO MATCH CASEWORK FACE, UNO INSTALL BLOCKING AS REQUIRED 3" MAX 1" MIN
