A floor roller assembly featuring a two-and-three-quarter-inch diameter roller mounts to the floor adjacent to a tilt-up concrete wall. Guide rollers secure to the floor using one nine-sixteenth-inch hole and one nine-sixteenth-inch slot, with anchors supplied by the installer. A four-wire fail-safe reversing edge and ME113 sensing edge integrate into the assembly.
OVERLAP 1' - 0" 1' - 0" 4 WIRE FAIL SAFE REVERSING EDGE ME113 SENSING EDGE FLOOR ROLLER ASSEMBLY (WITH 2 3/4"DIA. ROLLER) (1) 9/16" HOLE AND (1) 9/16" SLOT IN GUIDE ROLLERS TO ANCHOR TO FLOOR (ANCHORS SUPPLIED BY INSTALLER) 0' - 6 3/4" TILT UP CONCRETE WALL
