A one and one-half inch diameter outer diameter tube handrail is supported by wall-mounted brackets attached at intervals along the stair run. The bracket attachment method varies depending on the specific wall construction of the metal stair system. Vertical clearances are dimensioned at three feet zero inches minimum for the handrail height above the stair nosing.
1 1/2" DIA. O.D. TUBE WALL MOUNTED BRACKET ATTACHMENT VARIES W/ WALL CONSTRUCTION METAL STAIR SYSTEM, SEE DETAILS 1' - 0" 3' - 0" MIN. 1' - 0" 3' - 0"
