Architectural · A-XVTA4

Shelf At Column

Materials

Elements

About this detail

An acoustical curtain wall designated as CW-2 frames into an aluminum acoustical mullion trim cap, incorporating acoustical gaskets at glazing and framing junctions. The aluminum panel features a butt joint aligned with the centerline of the structural steel column typically. Acoustical sealant and backer rod seal the joint around the steel column profile, providing a one-quarter inch clearance. An adjacent acoustical curtain wall designated as CW-4 continues the assembly.
