Electrical connections at the Rae joint are positioned at elevation 124'-5" relative to the column centerline. The assembly includes structural steel shapes, mounting brackets, conduit runs, and joint sealing components. Dimensions indicate a spacing of eleven inches between connection points and a two-inch offset from the reference line. Conduit routes through the framing members with specific clearances maintained at the joint.
