The detail illustrates a framing and drywall intersection where an acoustic wall assembly meets an exterior wall. Callouts direct the extension of gypsum board to the outside face of the exterior stud and specify filling the exterior stud cavity with batt insulation. It includes light-gauge steel stud framing and layered gypsum wallboard finish.
Text on the drawing
B ACOUSTIC WALL ASSEMBLY, RE: FLOOR PLANS WALL ASSEMBLY, RE: FLOOR PLANS EXTERIOR WALL ASSEMBLY EXTEND GYPSUM BOARD TO OUTSIDE FACE OF EXTERIOR STUD. FILL EXTERIOR STUD CAVITY WITH BATT INSULATION. EXTEND GYPSUM BOARD TO OUTSIDE FACE OF EXTERIOR STUD. 3
