A 16-gauge by 1-1/2-inch galvanized corrugated metal gate is framed with angle iron or tubular steel. Heavy-duty lockable hardware and a 3/4-inch stock sliding lock mechanism engage with a 3/16-inch metal plate featuring a 2-inch overhang that acts as a gate stop. All steel bolts, angles, and related components are painted to match the building field color unless noted otherwise.
