This interior partition detail shows a cold-formed metal stud wall framing assembly extending from the finished floor slab to the underside of the structure above. The framing consists of six-inch metal studs running continuously to structure, filled with three-and-a-half-inch minimum sound attenuation batt insulation in the stud cavity. Each side of the partition is finished with two layers of five-eighths-inch Type X gypsum wallboard. A scheduled base is detailed at the line of finished floor. An alternate configuration, designated A1, utilizes three-and-five-eighths-inch studs.
3 1/2" MIN. SOUND ATTENUATION BATT IN STUD STUD CAVITIES 6" METAL STUDS TO STRUCTURE ABOVE - SEE STUD SCHEDULE FOR GAUGE AND SPACING (2) LAYERS 5/8" TYPE 'X' GYPSUM WALLBOARD EACH SIDE LINE OF FINISHED FLOOR. SCHEDULED BASE 6 3 UNDERSIDE OF STRUCTURE SEE SHEET A8.01A FOR UL CUT SHEET FOR REFERENCE A1 SAME AS 'A' EXCEPT 3 5/8" STUDS 3
