A vision panel is installed within a 1 3/4 inch solid core wooden door using a painted low-profile twenty gauge steel frame. The assembly incorporates a seven-eighths inch Pyrostop vision glass secured within the frame opening. Overall frame outside dimensions and glass sizing tolerances are dimensioned across the centerline.
SOLID CORE WOODEN DOOR 7/8" PYROSTOP VISION GLASS 1 3/4" 5/64" 5/64" PTD LOPRO -BB1, 20 GA STL FRAME 1/2" 1" STAIR 3'- 9" VISION PANEL 3' - 10" GLASS SIZE 3' - 11" ORDER SIZE/ DOOR CUTOUT 4' FRAME O.D. 1" 1/2"
