Front approach requirements establish a forty-eight-inch minimum clearance parallel to the sliding door. Pocket or hinge approach requirements specify forty-two inches perpendicular and twenty-two inches parallel minimum clearances. These dimensions comply with accessibility standards for approach pathways.
9. MANEUVERING CLEARANCES AT SLIDING DOORS (404.2.3.3) 48" MIN 42" MIN 22" MIN A: FRONT APPROACH B: POCKET OR HINGE APPROACH
