The tactile sign features five-eighths inch raised characters and grade two braille, positioned with a maximum mounting height of sixty inches to the top of the sign and a minimum of forty-eight inches to the baseline of the braille. The sign measures eight inches wide by six inches high and includes required notes specifying placement nine inches laterally from the adjacent door jamb.
MAINTENANCE ROOM 6" 8" NOTE: TACTILE SIGNS SHALL BE CENTERED 9" LATERALLY FROM THE DOOR JAMB OF ADJACENT DOOR. AT 48" MIN. 5/8" RAISED CHARACTERS BRAILLE AT 60" MAX. NOTE: TACTILE SIGNS SHALL BE CENTERED 9" LATERALLY FROM THE DOOR JAMB OF ADJACENT DOOR. AT 48" MIN. 5/8" RAISED CHARACTERS BRAILLE AT 60" MAX. 7 SIGN - ROOM SIGN
