Corner geometry of an indoor swimming pool gutter assembly. Gutter width is 1'-0 3/4". A 6" wide drainage or perimeter zone is adjacent to the gutter. The assembly includes a 4" wide return or edge condition at the corner. The layout utilizes a mitered corner transition for the gutter channel to maintain continuous flow and alignment.
