An insulated steel sectional door header and jamb interface incorporating a three-eighths-inch bent plate jamb guard anchored back to the wall structure with one-half-inch diameter wedge anchors spaced at twenty-four inches on center. The jamb guard extends to plus four feet zero inches and is finished with two coats of safety yellow gloss enamel paint. A heavy-duty track supports the door mechanism, while a continuous weather seal runs all around the perimeter.
VARIES, SEE PANEL NOTES 4" 4" 6" 1/2" DIA. WEDGE ANCHORS @ 24" O.C. 3/8" BENT PLATE JAMB GAURD TO +4'-0" PAINT SAFETY YELLOW (2) COATS GLOSS ENAMEL. HEAVY DUTY TRACK STEEL SECTIONAL DOOR (INSULATED) LOCATE DEAD BOLT LATCH 12" AFF WEATHER SEAL, ALL AROUND
