A quartz agglomerate countertop is supported by a plastic-laminate-clad architectural base cabinet over a finished floor. A fire-retardant-treated plywood backing panel is provided behind the counter assembly. The countertop extends two feet one inch from the backing panel, with a base toe kick measuring four inches high and three inches deep. Overall height from the finished floor to the top of the counter is two feet ten inches.
3/4" 3/4" 123661.19 QUARTZ AGGLOMERATE COUNTERTOPS 064116 PLASTIC-LAMINATE-CLAD ARCHITECTURAL CABINET FINISHED FLOOR 4" 3" 16 15 17 14 2' - 1" 9 12 13 061053 FIRE-RETARDANT-TREATED PLYWOOD BACKING PANEL 15 18 1" 2' - 10" 4" SIM 21 1 1/2" = 1'-0" 3 TYPICAL BASE CABINET WITH SINK
