Architectural · A-XDBM4

S3

Units: imperial
Sheet: A6.01
Discipline: Architectural

Materials

Cold-formed Steel Gypsum / Drywall Steel Timber / Wood

Elements

Partitions Walls

Text on the drawing

STEEL STUD GWB. (2) LAYERS ONE SIDE WALL TAG IS PLACED IN PLAN ON SIDE OF WALL WITH EXTRA GWB LAYER
