Solo wood baffle blades feature factory-cut notches that receive metal T-angles, which attach back to the overhead structure. All sides of the wood blades are finished faces with a one-quarter inch spacing between components. Concealed head fasteners secure the wood blades to the metal T-angle supports. The adjacent partition assembly is installed as scheduled.
1" 1/4" ALL SIDES OF WOOD BLADES TO BE FINISHED FACES ATTACH SOLO BAFFLE BLADES TO METAL "T" ANGLE USING CONCEALED HEAD FASTENERS FACTORY CUT NOTCH TO RECEIVE METAL "T" ANGLE METAL "T" ANGLE , ATTACHED TO STRUCTURE STRUCTURE REQUIRED FOR METAL "T" ANGLE ATTACHMENT PARTITION AS SCHEDULED
