A metal deck runs parallel over a steel beam sized per plan, featuring a deck filler matching the deck gauge as required. The metal deck is specified per the schedule on drawing S0.01 with a roof assembly defined by the architect. Typical sideseam connections are provided per the metal deck schedule at the deck filler and metal deck interface.
