An elevator floor signage assembly of Type C consists of an eighth-inch by eleven and three-quarter inch by seven-inch acrylic backing plate with backpainted color to be determined. The face panel comprises a one-sixteenth-inch by eleven and three-quarter inch by seven-inch non-glare acrylic plate with radius corners, subsurface vinyl border, and subsurface vinyl message. One-thirty-second-inch raised white letters form the four-inch floor number. Grade 2 Braille dots are integrated near the lower portion of the sign.
TYPE `C' 1 1/32" RAISED LETTERS, 4" NUMBER, COLOR: WHITE SUBSURFACE VINYL MESSAGE SUBSURFACE VINYL BORDER 1/16" X 11 3/4" x 7" NON-GLARE ACRYLIC WITH RADIUS CORNERS BACKPAINTED COLOR: TBD BRAILLE GRADE 2 1/8" X 11 3/4" X 7" ACRYLIC COLOR: TBD 1 1/2" 7" 7"
