A-XB85M — Acoustical Tile Ceiling Transition to Gypsum Board Soffit

Architectural · A-XB85M

Acoustical Tile Ceiling Transition to Gypsum Board Soffit

Materials

Steel Metal (misc.)Gypsum / Drywall

Elements

About this detail

An acoustical ceiling tile system meets a gypsum board ceiling soffit framed with bidder-designed metal runner channels. An F-moulding transition trim provides the edge detail where the acoustical tiles abut the vertical gypsum board face. The gypsum board ceiling height is referenced per the reflected ceiling plan.

09 21 16 F TRANSITION MOULDING 09 51 00 ACT 09 21 16 GYPSUM BOARD CEILING HT SEE RCP 09 21 16 METAL RUNNER CHANNEL SOFFIT FRAMING - BIDDER DESIGNED
