Metal furring studs support a 5/8-inch Type X gypsum board finish terminating against an existing concrete wall with a metal J-mold trim piece. Insulation fills the cavity where required for partition framing, with partition framing sizes governed by the wall stud table and referenced details.
EXISTING CONCRETE WALL METAL J-MOLD 5/8" TYPE "X" GYP. BD. ON METAL FURRING STUDS. INSULATION WHERE OCCURS FOR PARTITION FRAMING, SEE WALL STUD TABLE & REFERENCED DETAILS. SCALE: 6" = 1'-0" 14 MARKER RAIL
