An existing pad mount transformer labeled RC-433 is specified with a rating of 150kVA/EQ#36218, transforming 12kV to 208Y/120V, 3-phase, 4-wire fused service serving 1739, 1743, 1747, and 1751 Douglass Road. The installation includes 6-inch conduits and #1/0 aluminum EPR triplex cables over a length of 80 feet. Specific notes direct the removal of approximately 20 feet of existing 3#2 aluminum cable, as well as pole PP#26994D spanning 50 feet, per the demolition plan.
