A 3/8-inch pipe handrail turns into a partition wall type defined per plan, providing a 1 1/4-inch outside diameter and a 1 1/2-inch clearance from the finished wall surface. The handrail features a mitered corner at the return, which connects back to the guard, wall, or floor as required. Necessary backing is installed within the partition to support the handrail return connection.
OD 1 1/4" CLR 1 1/2" 3/8" PIPE HANDRAIL MITERED CORNER PARTITION TYPE PER PLAN WITH BACKING AS NECESSARY TYPICAL RETURN TO GUARD, WALL, OR FLOOR AT ALL HANDRAILS
