Vertical trim transition between a preformed metal panel system and a sintered compact surface panel system over their respective substructure framing. A prefinished sheet metal flashing bridges the junction, sealed with a continuous backer rod and sealant joint. The adjacent wall assembly varies per plan and integrates with the exterior cladding substructure.
PREFINISHED SHEET METAL FLASHING BACK ROD AND CONTINUOUS SEALANT, TYP WALL ASSEMBLY PER PLAN VARIES SINTERED COMPACT SURFACE PANEL SYSTEM PER ELEVATIONS OVER SUBSTRUCTURE SYSTEM PREFORMED METAL PANEL OVER SUBSTRUCTURE SYSTEM
