An expansion joint assembly bridges the structural separation between floor slabs supported by wide-flange steel beams. The detail incorporates a specialized expansion joint cover system set flush with the finished floor level at Level 03 and Level 03.1. Thermoplastic sheet waterproofing is integrated below the assembly to maintain continuous moisture protection across the structural break.
LEVEL 03 - HH CONCOURSE 135'-4 3/4" LEVEL 03.1 - CONCOURSE 137'-4 3/4" 9R SF TYPE LEGEND: BLUE = INTERIOR EJ RED = EXTERIOR EJ KEYNOTES MV DESCRIPTION 07 13 54 THERMOPLASTIC SHEET WATERPROOFING
