An acoustically rated partition supports a three-quarter-inch plywood substrate finished with wall panel type WP-5 on both sides. A one-eighth-inch aluminum horizontal reveal integrates with a wall panel clip system between the plywood layers. A light fixture is accommodated where it occurs, and all penetrations are sealed per plan and as scheduled.
1/8" ALUMINUM HORIZONTAL REVEAL WITH WALL PANEL CLIP SYSTEM 3/4" PLYWOOD 3/4" PLYWOOD WP-5 WP-5 ACOUSTICALLY RATED PARTITION PER PLAN AND AS SCHEDULED - SEAL AROUND ALL PENETRATIONS WHERE OCCUR 1/8" LIGHT FIXTURE WHERE OCCURS
