A hollow structural section beam frames into a wide flange column using bolted angle and tee connections. Three-eighths-inch thick stiffener plates reinforce the connection, welded with quarter-inch fillets on three sides typically. A WT 6x13 tee shape is welded to the wide flange beam with quarter-inch fillet welds. A pipe support is attached per detail two on sheet zero-one-seventy-dash-S-zero-one-dash-fifty-twenty.
1/2" 1/4 1/4 HSS BEAM TO WIDE FLANGE COL CONN, SEE / 3 017-S-01-5018 1/4 1/4 3 SIDES, TYP 1/4 1/4 WT STIFFNER TO WIDE FLANGE BEAM WT 6x13 PIPE SUPPORT, SEE 3/8" STIFFNER PL, TYP SECTION TYP 1 1/2" / 2 017-S-01-5020 9 8 7 6
