Precast concrete wheel stops are specified with a minimum 3000 PSI compressive strength and an off-center configuration. The profile view shows a 6-foot overall length with drainage openings and anchor pin locations. Steel pins of 3/4-inch diameter secure the bumper to the paving, with pin lengths specified as 12 inches for asphalt pavement areas and 24 inches for porous pavement areas. The side view indicates a height of 4.5 inches with preformed pin holes.
1' 1' 1' 1.5' MIN. DRAINAGE OPENING 1.5' MIN. DRAINAGE OPENING NOTES: 6" MIN 6" MIN 6' 3/4" DIA. STEEL PINS 6" 4.5" PROFILE VIEW SIDE VIEW 1. BUMPERS MUST BE PRE-CAST CONCRETE, 3000 PSI, AND MUST BE AS SHOWN OR SIMILAR IN OFF CENTER CONFIGURATION. 2. PIN LENGTHS MUST BE 12" IN ASPHALT PAVEMENT AREAS AND 24" IN POROUS PAVEMENT AREAS.
