An exposed outside corner of gypsum wall board receives a stainless steel corner guard measuring two inches by two inches by forty-eight inches high. The wall framing consists of metal studs sized per plan, with wall types varying according to the architectural floor plan.
FOR WALL TYPE VARIES, SEE PLAN STAINLESS STEEL 2"X2"X48"H CORNER GUARD AT ALL EXPOSED OUTSIDE CORNERS OF G.W.B. FOR WALL TYPE VARIES, SEE PLAN CORNER GUARD
