Mechanical · A-WXFG9

Daikin Vrf Condensing Unit

Elements

About this detail

The master outdoor unit of the largest tonnage and the slave outdoor unit are situated within frame A and frame B in the amenity rooftop mechanical area. Each unit connects to equipment grounding conductors. Low-voltage control wiring utilizing eighteen-gauge two-conductor stranded non-shielded cables routes through Q1, Q2, F1, and F2 terminals. Future connections extend via eighteen-gauge two-conductor stranded non-shielded low-voltage wiring to a future branch controller.
