A 1 1/2-inch outer diameter tubular handrail is secured to the wall via wall-mounted bracket attachments that vary according to the supporting wall construction. The handrail maintains a 3-foot-zero-inch height above the metal stair system, positioned with a 1-foot-zero-inch minimum extension. The stair assembly anchors down to a reinforced concrete slab foundation.
1 1/2" DIA. O.D. TUBE WALL MOUNTED BRACKET ATTACHMENT VARIES W/ WALL CONSTRUCTION METAL STAIR SYSTEM, SEE DETAILS 1'-0" 3'-0" MIN. 1'-0" 3'-0"
