Mechanical ducts are installed within separate stud bays of two-by-six wood framing. Stud spaces are filled with insulation around the duct penetrations. Wall assembly and framing configurations are coordinated with the floor plan and mechanical drawings.
WALL ASSEMBLY SEE: . MECHANICAL DUCT-INSTALL MULTIPLE DUCTS IN SEPARATE STUD BAYS-SEE MECHANICAL DRAWINGS INSULATE STUD SPACES 2X6 FRAMING (WHERE OCCURS)-SEE FLOOR PLAN
