An aluminum mullion section serves as the storefront head frame, positioned above a concrete tilt-up panel with a three-eighths inch vertical clearance. A sealant bead over backer rod fills the joint between the storefront frame and the concrete panel. Glazing is installed within the aluminum framing section per elevations and specifications. A four-inch dimension locates the framing relative to the exterior face.
