Metal studs are positioned on both sides of a hollow structural section post and attached with number 10 self-drilling screws spaced at twelve inches on center. A base plate is installed inside the bottom track. Wall framing is provided as scheduled at sixteen inches maximum spacing. Reference detail 3 on sheet AE512 for the corresponding section view.
METAL STUD ON BOTH SIDES OF HSS POST; ATTACH TO POST W/ #10 TEC SCREWS @ 12"O.C., TYP BASE PLATE INSIDE BOTTOM TRACK, TYPICAL WALL AS SCHEDULED 16" MAX, TYP. 16" MAX, TYP. NOTE: REFER TO DETAIL 3/AE512 FOR SECTION VIEW.
