A coiling door mechanism is mounted adjacent to a structural steel beam and concrete floor slab system. The assembly includes a rolled steel beam with fireproofing, a concrete floor slab at level 2, and the coiling door housing unit positioned below the slab edge. Grid line G establishes the structural alignment, with dimensional ties indicating the spatial relationship between the grid and the slab edge.
