A hollow metal steel door jamb bears on a concrete slab at the base connection. Two three-eighths inch expansion bolt anchors secure each jamb with a minimum three-inch embedment into the top of the concrete. A finish floor transitions at the threshold with a three-eighths inch door undercut.
HM STEEL DOOR JAMB BEYOND BASE ANCHOR (SCHEDULE BELOW) DOOR UNDERCUT 3/8" DOOR FRAME ANCHORS - REFER TO FRAME ANCHOR SCHEDULE (2) 3/8" KB-TZ EXP BOLT ANCHORS PER JAMB WITH MIN 3" EMBEDMENT FINISH FLOOR 0'-0" TOP OF CONC. 3/8" 5 7/8" NOTES: SEEE DETAIL FOR FRAME ANCHOR SCHEDULE. / 08 A9.21
