A precast concrete stair assembly designated as SP-2 spans a total width of fifteen feet zero inches. The stair run includes an eight-foot zero-inch section alongside a variable width dimension "X" per the stair panel schedule with a seven-inch end clearance. Concrete treads slope toward the exterior, and treads are coordinated with architectural drawings for exact profiles. A steel pipe handrail is integrated into the assembly per architectural drawings. The stair connects to the building wall at the interior boundary, referencing grid line B5 and detail 7 on sheet SD.1.
