Scheduled carpet and backing meet at a stone threshold where widths vary and profiles require approval. The nap of the carpet is kept above the adjacent floor finish. The floor assembly consists of scheduled carpet and backing installed over a concrete slab.
SCHEDULED CARPET AND BACKING. KEEP THE NAP OF THE CARPET ABOVE ADJACENT FLOOR FINISH SCHEDULED CARPET AND BACKING.KEEP THE NAP OF THE CARPET ABOVE ADJACENT FLOOR FINISH STONE THRESHOLD, SUBMIT PROFILE FOR APPROVAL; WIDTHS VARY.
