An accessible toilet stall side wall layout establishes spatial clearances and mounting heights for a combined soap dispenser and paper towel unit relative to the water closet. The combined soap and towel dispenser mounts adjacent to the water closet with a maximum height of four feet to the top operative part and a minimum height of eighteen inches to the bottom. Horizontal clearance dimensions of thirty-six inches define the required spacing from the side wall.
BB WC CSD STANDARD TOILET STALL SIDE WALL COMBINED DISPENSER 36" 4'-0" MAX 18" MIN 36"
